Sound Devices MixPre-3 II Preamplificator Recorder 3 Canale

Referinţă: 125048401

Deschidere la livrare

Garantie

Specificatii tehnice

ProprietateSpecificație
Warranty Length
24

Specificatii tehnice

ProprietateSpecificație

Sound Devices MixPre-3 II Preamplificator Recorder 3 Canale

Descriere

Sound Devices MixPre-3 II Preamplificator Recorder 3 Canale

store/product-description.title

Sound Devices MixPre-3 II ofera o interfata audio USB cu pana la 5 intrari si 2 iesiri cu 3 preamplificatoare Kashmir si abilitatea de a face stream pentru pana la 3 semnale de intrare analogice (inclusiv 3 intrari de microfon de inalta calitate) plus mixare pentru 2 canale pe USB. Este echipat cu control gain ergonomic pentru mixare rapida si exacta, dar poate de asemenea sa fie controlat de la distanta prin intermediul Bluetooth de pe aplicatia gratuita Wingman. Utilizatorii pot porni si opri inregistrarea, introduce si edita metadata, precum si sa incarce, descarce sau sa redenumeasca track-uri audio de pe telefon sau tableta.



  • Caracteristici:
  • Trei preamplificatoare de microfon Kashmir cu zgomot ultra-scazut, cu limitatoare reglabile, capteaza audio de inalta calitate in teren, in studio sau cu un computer.
  • Creati un mix folosind mixerul portabil integrat 3 x 2.
  • Inregistrati pana la 5 track-uri pe un card SD si copie de rezerva pe un stick USB.
  • Interfata audio USB de 5 intrari, 2 iesiri, transmite pe computer prin USB-C.
  • Alegeti adancimile de biti de la 16 la 32 de biti float si ratele de esantionare de la 44,1 kHz la 192 kHz.
  • Generator de timecode interne LTC. Timecode In / Out prin Aux In / Out Stereo.
  • Timecode si inregistrare declansare prin HDMI.
  • USB-A pentru suprafete de control, tastaturi si copiere automata pe unitatea USB.
  • In-unit ISO mixing, gain, pan, low-cut, phase inversion, si phantom power
  • Ecran tactil LED care poate fi citit in lumina soarelui
  • Usor, durabil si portabil
  • Amplificatorul de casti puternic de 300 mW + 300 mW permite trimiterea clara si precisa a sunetului.
  • Alimentare cu baterii MX-4AA (baterii neincluse), alimentare MX-PSU AC si cablu USB-C la USB-C.



Intrari Audio
  • Frecventa
    • 10 Hz la 80 kHz +/- 0.5 dB re 1 kHz @ 192 kHz sample rate
  • THD + Noise
    • 0.005% max (@1 kHz, 22-22 kHz BW, gain= 20 dB, -10 dBu in)
  • ADC
    • 32 bit precision; 142 dB dynamic range min (A weighted, gain = 10 dB, fader = 0 dB)
  • Equivalent Input Noise
    • -130 dBV (-128 dBu) max (A-weighting, gain = 76 dB, 150 ohm source impedance)
  • Intrari
    • Mic: XLR active-balanced; 4k input
    • Line: XLR active-balanced; 4k input
    • Aux/Mic in: 3.5 mm TRS, 2-channel unbalanced; 100k input
    • USB Audio: 2 channels
    • Toate intrarile filtrate complet RF si protejate la suprasarcina
  • Gain
    • Mic input: +6 dB to +76 dB
    • Line input: -20 dB to +30 dB
    • Fader: -inf to +20 dB
    • Headphone: -inf to +20 dB
    • Total, Mic-to-recording (max): +96 dB
    • Aux In (Mic): Gain = +10 dB to +40 dB
    • Aux In (Line): Gain = -10 dB to +20 dB
    • Total Aux Gain including Fader (Mic-to-recording): +60 dB
  • Maximum Input Level
    • Mic XLR: +14 dBu (limitatoare activate sau dezactivate)
    • Line XLR/¼-inch: +28 dBu (limitatoare activate sau dezactivate)
    • Aux In (Mic): -10 dBu
    • Aux In (Line): +10 dBu
  • Low Cut Filters
    • 40 Hz to 160 Hz (reglabil), 18 dB/oct. First stage analog, subsequent stages digital.
  • Microphone Powering
    • Mic XLRs: 48 V via 6.8k resistors, 10 mA each
    • Mic 3.5 mm: 3 V @ 3k source
  • Limitatoare
    • Limiter at all gain stages, range > 40dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release.
Audio Outputs
  • DAC feeding Stereo Out, Headphone Out
    • 32 bit precision; 115 dB dynamic range (A-weighted)
  • L/R Out
    • 3.5 mm TRS stereo unbalanced, 500 ohm output impedance, +7.8 dBu max output level
  • Headphones Out
    • 3.5 mm TRS stereo unbalanced, 300 mW + 300 mW, for use with any impedance headphones
USB
  • Audio Interface (USB-C): 5-in/2-out (from computer); 44.1 kHz/48 kHz/96 kHz; 16/24-bit; Class-compliant USB 2.0 high speed driver
  • Mass Storage (USB-C): USB 2.0 high speed
  • Keyboard (USB-A): Text entry and control
  • Thumbdrive (USB-A): Manual or auto-copy to drive
  • Midi Control Surface (USB-A)
Recording
  • Maximum Record Tracks
    • 5 Tracks Stereo mix + 3 ISO's
  • Sampling Frequency
    • 44.1 kHz
    • 47.952 kHz
    • 48 kHz
    • 48.048 kHz
    • 96 kHz
    • 192 kHz
  • Bit Depth
    • 16
    • 24
    • 32 Float
  • Recording Storage
    • Type: SD, SDXC, SDHC Card, & USB thumbdrive (copy only)
    • Max Storage Size: 512 GB (SDXC)
    • Card format: exFAT
  • File Type
    • Polyphonic WAV
Timecode
  • Timecode Modes
    • Free Run
    • Time of Day (file stamped w/current ToD)
    • Rec Run
    • Ext LTC (file stamped w/incoming LTC on 3.5mm Aux In)
    • Camera TC (file stamped w/incoming TC from cameras that output TC)
  • Timecode Frame Rates
    • Auto-detects (fps): 23.98 (same as 23.976)
    • 24
    • 25
    • 29.97DF
    • 29.97ND
    • 30
    • 30DF
  • 3.5 mm Aux In
    • Timecode Input
    • Timecode: 20k ohm impedance, 0.3 V - 3.0 V p-p (–17 dBu - +3 dBu)
  • 3.5 mm Stereo Out
    • Timecode Output
    • Timecode: 1k ohm impedance, 3.0V p-p (+12 dBu)
  • HDMI
    • TC Reader via HDMI
  • Sample/Timecode Accuracy
    • 0.2 ppm (0.5 frames per 24 hours)
Remote Control
  • Bluetooth LE: Wireless control using Wingman app
  • HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI
  • Timecode: Auto-record start/stop trigger via Aux In timecode
Touch Screen
  • 320x256; 1.6-inch, color, sunlight-viewable IPS LCD
Power
  • AA Batteries: 4x AA
  • L-Mount: Optional sled for 2x (hot-swappable) Li-ion batteries
  • From computer: Bus-powered via USB-C port
  • AC Adapter: MX-PSU (included) Power supply wall adapter w/ USB-C connector; 15 W; has 4 adapter plugs for US, UK, AU & Europe
Conditii de mediu
  • Operare: -20°C la 60°C, 0 la 90% umiditate
  • Depozitare: -40°C to 85°C
Dimensiuni
  • Dimensiuni: 36 mm x 144 mm x 110 mm
  • Weight: .48 kg; 16.8 oz. (unpackaged, without batteries)

Descrierea bunurilor sau a serviciilor disponibile pe www.f64.ro (prin imagini, video etc.) nu reprezinta o obligatie contractuala din partea F64, acestea fiind utilizate exclusiv cu titlu de prezentare. Implicit F64 Studio S.R.L. nu isi asuma raspunderea pentru eventualele erori de pret sau stoc. Aceste erori nu obliga F64 Studio S.R.L. la nicio actiune. Preturile si disponibilitatea produselor comercializate de catre F64 Studio SRL pot suferi modificari ulterioare, acest lucru fiind influentat de factori externi precum politica de preturi a distribuitorilor sau disponibilitatea produselor pe stocul acestora. De asemenea, F64 Studio S.R.L. isi rezerva dreptul de a corecta eventuale omisiuni sau erori in afisare care pot surveni in urma unor greseli de dactilografiere, lipsa de acuratete sau erori ale produselor software, fara a anunta in prealabil.

ID-ul itemului: 310790

Specificatii

Sound Devices MixPre-3 II Preamplificator Recorder 3 Canale

Recordere audio / Reportofoane
Intrari Audio
5
Microfon Incorporat
Nu
Interfata Intrare
XLR/USB
Iesire Casti
Da
Alimentare
AA
Rata Maxima Esantionare
32bit/192Khz
